PDS108KF
Brochures
| Busbar voltage (VDC) | 660 |
| Ratio | 9.6 |
| Rated power (kW) | 2x120 |
| Peak power (kW) | 2x280 |
| Wheel rated speed (rpm) | 593 |
| Wheel peak speed (rpm) | 1560 |
| Wheel rated torque (N·m) | 2x1860 |
| Wheel peak torque (N·m) | 2x4350 |
| Drive form | Central Distributed Drive |
| Assembly power density (kW/kg) | 4.6 |
| Assembly maximum efficiency | 93% |
| Assembly weight (kg) | 120 |
| Assembly dimensions (mm) | 500.8x484.2x374.2 |
