  • Construction Machinery Field
  • Navigation Machinery Field
  • Rated voltage (VDC)

    540

  • Rated power (kW)

    111

  • Peak power (kW)

    188

  • Rated speed (rpm)

    3200

Brochures

Rated voltage (VDC)540
Rated power (kW)111
Peak power (kW)188
Rated speed (rpm)3200
Peak speed (rpm)8000
Rated torque(N·m)330
Peak torque(N·m)800
Maximum efficiency96%
Cooling formWater cooling
Dimension(mm)φ410X164.6X518.5
Weight (kg)65
